High-Precision Roll-to-Sheet Cutting for Metal Foils and Vinyl Films.
The HX-400 Automatic Cutting Machine is engineered to process delicate roll materials into precise sheets. It is particularly effective for cutting Aluminum Foil, Copper Foil, Vinyl Decals, and Conductive Fabrics.
Unlike standard cutters that may wrinkle thin foils, this machine features a specialized feeding system that ensures the material remains flat and scratch-free during the cutting process. It is widely used in the electronics (EMI shielding), new energy, and printing industries.
Key Features
- Damage-Free Feeding: Soft rubber rollers prevent scratches on the surface of aluminum or copper foils.
- High Precision: Stepper motor control delivers a cutting accuracy of ±0.1mm, essential for electronic components.
- Clean Edges: The heavy-duty HSS (High-Speed Steel) blade ensures a sharp, burr-free cut even on metal foils.
- Versatile Handling: Capable of handling both thin films (0.05mm) and thicker insulation sheets.
- Batch Memory: Set the length and quantity once, and the machine repeats the job automatically.
- Anti-Static Option: Can be equipped with a static eliminator for cutting plastic films like PET or PVC.
Technical Specifications
| Model | HX-400 (Roll to Sheet Cutter) |
|---|---|
| Max Cutting Width | 400 mm |
| Compatible Materials | Aluminum Foil, Copper Foil, Vinyl, PET, Insulation Paper |
| Cutting Thickness | 0.02mm – 2.0mm (Depends on material) |
| Cutting Length | 0.1 – 9999.9 mm |
| Cutting Speed | 80 – 120 cuts/minute |
| Voltage | AC 220V / 110V, 50/60Hz |
| Machine Weight | Approx. 70 KG |
Applications
Designed for precision cutting in:
- Electronics: Aluminum/Copper foil for battery electrodes, EMI shielding foam, Conductive cloth.
- Insulation: Nomex paper, Barley paper (Insulation gasket), PET film.
- Graphics: Vinyl sticker rolls, Heat transfer vinyl, PVC sheets.
